BCAM 1325c CNC Router Machine for Wood Carvings Machine High Quality

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Browse by Category

Contact us

Bcamcnc
[China]

Address
Room 1502-2,Floor 15,Aosheng Building,Xinluo Ave Hi-tech Zone  Jinan Shandong
Phone
86-183-64117668
Contact name
sunqingxiao

Quick Information

  • Place of Origin: China
  • :

Description

Factory supply high precision atc cnc router 3d cnc machine automatic woodworking machine 1325C



BCM1325C with Japan Yaskawa servo motor and drivers



1  Working area: 1300*2500*200mm|4´*8´
2  CE standard
3  Italian HSD 9.5KW(12HP) Electrospindle with 8-position Automatic Tool Changer(ISO30)
4  10mm Heavy duty body
5  Active safety system
6  Helical rack and pinion drivers on X and Y axis, Z axis Taiwan TBI ball screw transmission
7  25mm Heavy-duty Hiwin HG Series linear bearing
8  Vacuum table+T-solts
9  Taiwan Syntec 6MA
10 Japan Yaskawa servo motor and drivers system
11 Delta brand VFD-B variable frenquency drive
12 8 Position Automatic Tool Changer (options: 10 ,12 position)
13 Tool Cone Holder-for east bit changing
14 Solid State limit switches
15 3 Years Warranty



Parameters

Standard Specifications BCM1325C

X,Y,Z Working Area

1300*2500*200mm|4´*8´

Optional Working Area1300*1300*200mm|4´*4´
1500*3000*200mm|5´*10´
2000*3000*200mm|6´*10´
2000*4000*200mm|6´*13´
2000*6000*200mm|6´*20´

Spindle Power

9kw Italy HSD air cooling  spindle

X,Y,Z Traveling Positioning Accuracy

±0.03/2000mm

Table Surface

Vacuum table+Intergrated T-solt table clamping System

X,Y,Z Rail and Trasmission

X Y axis gear transmission, Z axis TaiwanTBI Ball Screw

Max. Rapid Travel Rate

80m/min

Max. Working Speed

60m/min

Cutting thickness

According materials

Spindle Speed

6000-24000RPM

Drive Motors

Japanese Yaskawa Servo Drive System

Working Voltage

AC380v/50HZ/3 phase

Command Language

G code

Operating System

Taiwan Syntec 6MB control system

Interface

USB

Software Compatibility

Option:BCAMPRO/VCarve/VCarve Pro/ArtCAM/UCANCAM,etc.

Running Environment

Temperature: -20℃~45℃ Relative Humidity: 5%~75%

1. How to use the machine after receving the machine

Firstly , when you got machine , you need to contact with us ,our engineer will together with your to deal with it ,secondly ,we send user manuals and

 CD to you before you get the machine ,Thirdly Our professional technician online teach you until you can use it well by yourself.



2.Payment terms,There are 2 ways to pay money . 1)T/T, means international bank transfer. 30% deposit, we produce the machine for you. 70% before shipping.

 It is convenient and fast. 2)Alibaba Secure payment. Reliable and safe, Alibaba will charge a little handling fee.



3.How to choose a suitable machine?

You can tell us the working piece material, size, and the request of machine function. We can recommend the most suitable machine according to our experience.

Other kinds of payment we can consider if acceptable for us.



4.Do you have a setup and equipment commissioning service?

Yes,we have. The machine was installed and debugged before delivery. You can use the machine directly after receiving it. Of course, we also could let our technologists go to your country to install and debug the machine.


Packaging & Delivery

  • Packing :100
  • Packaging Size : 100 x 100 x 100
  • Package Weight : 100  Milligrams
  • Delivery Lead Time : 20
  • Supply Ability : Sets per Month

Product Image

  • BCAM 1325c CNC Router Machine for Wood Carvings Machine High Quality image
